Can be used to conveying water and other similar liquid with water properties
Model :
ARP20-40/130Imported caliber (DN) :
20Export caliber (DN) :
20Rated flow (m³/h) :
33/30/23Rated head (m) :
4/1.7/1Motor power (kw) :
22/18/10Material :
Cast iron pump casing/plastic impellerFOB Price （USD$） :
74Permanent Magnet Variable - Frequency Circulating Pump
Technical parameter:
Flow rate, Q: maximum 2.7 m³/h
Head, H: maximum 6.2m
Application environment
Can be used to conveying water and other similar liquid with water properties, suitable for constant flow and variable flow of heating system, different water supply temperature heating system, need evening automatic callback of the heating system, flow reduction pump pressure increase larger heating system, with the flow changes need automatic regulation performance of heating system, heating system pressurization and tap water circulation and pressurization.
Pump
Simple design and has a perfect integrated control unit;
Antirust cast iron pump body;
High quality engineering plastic impeller, can withstand 150℃ high temperature;
99% alumina ceramic rotating shaft;
Liquid temperature range: 2℃ -110℃;
Electrical Appliances
Insulation grade:H
Protection level: IP42
99% alumina ceramic bearings
Copper wire motor
Voltage / frequency (V / Hz): 220-240 / 50
Energy efficiency grade: 0.23, which meets the application environment specified in the EUP instruction
Horizontal type, using extended coupling, single-stage radial split volute (pump size larger than 125 adopts two-stage design) adopts back-pumping design, with replaceable shaft sleeve/shaft protection sleeve and replaceable pump body sealing ring, and the design conforms to ATEX；
