For conveying water and other liquids similar to water.
Model :
PQ50Imported caliber (DN) :
25Export caliber (DN) :
25Rated flow (m³/h) :
0.9Rated head (m) :
11Motor power (kw) :
0.11Material :
Cast iron pump casing/copper impellerFOB Price （USD$） :
58Miniature vortex centrifugal pump
Technical parameter:
Flow rate, and Q: Maximum 3m³/h
Head, H: maximum 55m
Application environment
For conveying water and other liquids similar to water. Suitable for household living water supply, automatic
Irrigation system, small air-conditioning system or supporting facilities, etc.
Pump
Cast iron pump body, after a special rust prevention process treatment
Copper impeller, copper insert; can effectively solve the impeller when the pump is idle for a long time card stagnation problem
AISI304 Stainless steel welded shaft
Maximum liquid temperature: + 60℃
Maximum suction and upper height: + 8m
Electrical Appliances
High efficiency bearing
Copper wire motor
Single-phase electric generator with built-in thermal protection device
insulation grade:F
Protection level: IPX 4
Maximum ambient temperature: + 40℃
Horizontal type, using extended coupling, single-stage radial split volute (pump size larger than 125 adopts two-stage design) adopts back-pumping design, with replaceable shaft sleeve/shaft protection sleeve and replaceable pump body sealing ring, and the design conforms to ATEX；
