Always clean water delivered due to water-contact parts produced by corrosion-resistant mateiral (but, not to use for drinking water) (PWN-350M)
Model :
PW-178EHImported caliber (DN) :
25Export caliber (DN) :
25Rated flow (m³/h) :
0.9Rated head (m) :
16Motor speed (rpm) :
2900Motor power (kw) :
0.3Material :
Pump casing: EN-GJL-200 Impeller: BrassVortex Pump
Technical parameters:
Flow rate, q: 60 m3/h max.
Head, h: up to 58m.
Pressure, p: max. 5bar
Temperature, t: 0℃-+40℃
Suction: 8m at most
Protection grade: IP44
Material Science
Pump casing: EN-GJL-200
Impeller: Brass
Terminal box cover: ABS
Impeller cover: brass
Shaft: Stainless steel 1.4006
Mechanical seal: carbon/ceramic
Feature:
Self-Priming
Automatic operation by pressure switch
Application:
Well
Small to medium-sized building
Water supply tank
Water storage tank spraying
Water storage tank irrigation and watering
Rainwater collection in storage tanks
Horizontal type, using extended coupling, single-stage radial split volute (pump size larger than 125 adopts two-stage design) adopts back-pumping design, with replaceable shaft sleeve/shaft protection sleeve and replaceable pump body sealing ring, and the design conforms to ATEX；
Read More
Product overview Horizontal, single-machine direct-connected single-stage radial split volute, rated power conforms to EN 733 standard, with replaceable shaft sleeve and pump body sealing ring, and the design conforms to ATEX
Read More
A vertically installed multistage high-pressure centrifugal pump with annular cross-section design is equipped with suction nozzles and nozzles (pipeline design) with the same nominal diameter and relatively designed positions, which are directly connected and designed according to ATEX；
Read More
CR and CRE pumps are non-self-priming, vertical multistage centrifugal pumps.
Read More
Always clean water delivered due to water-contact parts produced by corrosion-resistant mateiral (but, not to use for drinking water) (PWN-350M)
Read More
