Wilo PB Non-Self-Priming Single-Stage Centrifugal Pump With A Series Structure
Wilo - PB is a single - stage centrifugal pump without self - priming function, which is used for automatic water supply and pressure boosting. It is suitable for being installed below roof water tanks (such as elevated water tanks) to supply water to the lower extraction points of one or two - family houses. It is suitable as a water pump in public water supply networks with low water pressure or water pressure fluctuations. Due to its automatic mode, it can always ensure stable water pressure.
Model :
Wilo-PB-088EAImported caliber (DN) :
G¾Export caliber (DN) :
G¾Rated flow (m³/h) :
1.5Rated head (m) :
4Motor power (kw) :
80WMaterial :
Pump casing: Grey cast iron/Impeller: PlasticSingle-stage centrifugal pump
Technical parameters:
Flow rate, q: 75m3/h max.
Head, h: up to 20m.
Pressure, p: max. 5bar
Temperature, t: 0℃-+100℃
Material
Pump shell: gray cast iron
Impeller: plastic
Shaft: stainless steel
Mechanical seal: carbon/ceramic
Engineering data
Power supply connection 1 ~ 230 V 10%, 50 Hz
Interfaces (pressure side and suction side): G ",Rp1, RP1"–depending on specific specifications.
Fluid temperature:+5 C to+80 C.
Ambient temperature: 0 °C to 40 C.
Storage temperature:-20 C to+60 C.
Maximum inlet pressure: 3.0 bar
Maximum working pressure: 5.0 bar
On/off volume flow: 2 l/min
Protection level: IPX4
Provide safe and stable booster for residential areas.
Wilo-PB is a single-stage centrifugal pump without self-priming, which is used for automatic water supply and
Boost. It is suitable to be installed under the roof water tank (such as overhead water tank) for
Pumping water to the lower part of one/two-family house. It is suitable as there is low water pressure.
Or a water pump in a public water supply network with fluctuating water pressure. With the automatic mode,
It can always ensure a stable water pressure.
Feature:
Flow Sensor
Centriful impeller, low noise
Constant working pressure
Application:
Roof tank to tap water transfer
Pressure boosting in household
Product advantages
> dry-turn protection brings high operation reliability.
> with automatic mode, hydraulic components have anti-corrosion coating, which is durable and reliable.
> unified design type, easy to install
>Compact design, low running noise (55 dbA), suitable for home use.
> automatic control makes power consumption lower.
