The LH series are cast iron high-lift three-phase drainage pumps. Their round and slender design allows them to be fitted with well pipes for deep well drainage. The intermediate flange structure ensures stable balance after installing the drainage pipe.
Model :
LH430Discharge Bore（mm） :
100Rated flow (m³/min) :
1Rated head (m) :
60Motor power (kw) :
30Weight (KG) :
355Material :
Cast ironHigh-lift drainage pump
Technical Parameters
Flow：6m³/min
Head：210m
Discharge Bore(mm)：180-200
Motor Output(kW)：3-110
Product Description
Tsurumi LH/LH-W series pumps are submersible heavy-duty pumps specialized for high head. These pumps are available in a wide lineup, offering 3 to 110 kW motor output and 18 to 230 m maximum head. The LH/LH-W series has played an active role in various fields,from small/medium-scale civil engineering and construction work that requires high reliability, to large-scale projects for constructing tunnels, bridges and dams. And, because of their slim body, these pumps have proven to be particularly useful for deep well dewatering and mine pit drainage where required to work in limited space.
In addition, the LH-D-series pumps, which are equipped with a 2-pole 110 kW/185 kW motor and double suction impeller, have been newly added to the product lineup to provide high volume, high head performance.
With a max. capacity of 14 m3/min and max. head of 92 m, the LH-D-series meets the needs of open-pit/underground mining, heap leaching and large-scale tunneling work.
Horizontal or vertical single-stage submersible pumps can be used as modular pump units. They can be equipped with various types of next-generation impellers, and can be installed in a wet or dry manner. They can be used statically or in combination with energy-saving motors in a mobile way. Explosion-proof models are also provided.
