GX Series Mechanical Diaphragm Metering Pump

Mechanical Diaphragm Metering Pump

Technical parameters:

Single head maximum flow: 2100L/h

Maximum discharge pressure: 9bar

Adjustment ratio 10:1, steady-state accuracy +2%6

Suction lifting height can reach 2.5m water gui

Maximum temperature of the material allowed 40%C

Product description:

GX series mechanical diaphragm metering pump is driven by eccentric mechanism, with compact structure; flow adjustment is variable confidence sliding shaft (Z-shaped shaft) adjustment mechanism; connecting rod drives the plunger, the diaphragm is installed on the plunger, and imported hydraulic seals are used.

Material:

Stainless steel, fluoroplastic, other materials

Application fields:

Applicable to petrochemical, chemical, electric power, metallurgy, medicine, food, etc., and widely used in water treatment work such as municipal, industrial water and wastewater, swimming pools, etc.

Performance and advantages:

Mechanically driven diaphragm, no diaphragm protection plate on the material side, easy for material to pass , PVC, PVDF, 31655, high viscosity, slurry and other pump head materials are optional, self-cleaning one-way valve structure variable eccentric mechanism adjustment to ensure smooth flow pulsation, suitable for various harsh working environments oil bath lubrication, long working life of driving components, flow regulation can be achieved in shutdown or running state.
